Operating Environment:Humidity up to 90% non-condensing
Weight:Approximately 5kg
Voltage Input:60 to 120V
Relay Dimensions:9”H, 7 ⅛”D, 7”W
Number of Logic Inputs:16
Fuse Type:.5 × 20 mm slow-blow Littelfuse
Analog Input Type:DC mA
Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz
Windings Per Phase:3
Resistant Temperature Device (RTD) Type:3 wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum
Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA
Maximum Continuous Voltage Output:273 V
Display Type:40 character Enhanced LCD
This advanced transformer management relay is equipped with three windings per phase and operates with a higher control power, offering enhanced functionality for managing and protecting transformer systems.
The GE 745-W3-P5-G5-HI-A-L-R-E-H features advanced monitoring capabilities, including individual harmonic analysis, total harmonic distortion measurement, and real-time adaptive correction for CT ratio mismatch.
It includes GE Multilin’s FlexLogic™ technology, which allows up to 20 configurable parameters for protecting and monitoring inputs and outputs, enhancing the system’s flexibility and adaptability.
External contacts can be connected via sixteen logic inputs, supporting both wet and dry contacts for versatile connectivity options.
With its robust design and advanced features, this transformer management relay ensures optimal performance and longevity of transformer systems, making it a vital component in industrial electrical infrastructure.
