Input Supply Voltage Rating:120 / 240 VAC, 1-Phase, 50-60 Hz
Continuous Output Current:5.7 Amperes
Number of Inputs:12 configurable
Indexing Functions:Multiple
Transmission Rate:10/100 Mbps
Maximum Installation Height:1500m (4921ft)
Operating Temperature Range:0 to 40 °C (32 to 104 deg. F)
Humidity Range:5 to 95% non-condensing
Transformer Requirement:750VA, 460V AC external transformer
Weight:1.5Kg (3.3lb)
Dimensions:238mm x 185mm x 68.0mm (9.3in x 7.29in x 2.68in)
The Allen-Bradley 2097-V31PR2 AC Drive is equipped with four (4) inputs per group, each with a dedicated common such as ACOM, BCOM, and CCOM. This modular design facilitates integration with CompactLogix and ControlLogix controllers supporting motion over Ethernet interfaces. The drive’s ethernet interface supports a transmission rate of 10/100 Mbps, enabling seamless communication within industrial networks.
With a focus on safety, the 2097-V31PR2 offers Hardwired Safe-Torque Off (STO) functionality, certified for use in safety-critical applications up to and including ISO 13849-1 performance level d (PLd). This ensures reliable operation in environments requiring high safety standards.
The drive’s robust construction allows for a wide operational temperature range of 0 to 40 °C (32 to 104 deg. F), making it suitable for various industrial settings. It is rated for installation heights of up to 1500 meters without any de-rating, providing flexibility for diverse installation scenarios.
Featuring twelve (12) configurable inputs, the 2097-V31PR2 enables users to adapt the drive to their specific application needs. Inputs are grouped into three (3) sets of four (4) each, facilitating easier configuration and management of external signals such as travel limit switches, push buttons, manual switches, and proximity sensors.
Designed with efficiency in mind, the Allen-Bradley 2097-V31PR2 AC Drive delivers optimized performance, enhanced reliability, and energy savings. Its versatile features and high safety standards make it an ideal choice for manufacturers and engineers seeking advanced motor control solutions in their industrial automation processes.
